M359-2 Series
Contact:
Description:
• FULL COMPLIANCE WITH MIL-STD-1399 (SECTION 300B)
• 3U RACKMOUNT
• 2.0KW/2.5KVA UPS
• 10-MINUTES HOLDUP TIME @ 1.5KW
Ruggedized, high performance On-Line UPS designed for Naval Shipboard and tough industrial applications.
Features & Benefits:
• Full Compliance with MIL-STD-1399, Section 300B, Type I Power (115VAC/60Hz)
• Internal Input Isolation Transformer
• A front panel loaded, Plug-in Battery Pack
• Optional Extended Holdup-time (9 minutes at 1.9KW)
• Real sine-wave 115VAC/60Hz output, synthesized from a crystal oscillator
• Very low Input Current Harmonic content (MIL-STD-1399 compliant)
• Better than 98% Input Power Factor
• Very low input-to-chassis capacitance (MIL-STD-1399 compliant)
• Full galvanic isolation between Input, Chassis GND and Output
• 1,000V / 50μs spike capability (MIL-STD-1399-300B compliant)
• Complies with MIL-STD-461F
• Complies with MIL-S-901D (Grade A, Class I &2) and MIL-STD-167-1 (Type I)
• Remote Panel ON/OFF capability
• By-pass mode, via internal Power Conditioner, Isolation Transformer and Relays
• MS Power Connectors
• RS-232 or Ethernet SNMP v1, v2 or v3 Control and Monitor
• J-STD-001B and IPC-610A Class-3 Workmanship
• Polyurethane Conformal Coating on PWB’s per MIL-I-46058C and IPC-CC-830
